Cannabis Extraction: Pure, safe and quality extracts
Why Cannabis?
Cannabis is a plant that is grown for its psychoactive and medicinal properties. The plant contains a number of chemical compounds known as cannabinoids, the most well-known of which is cannabidiol (CBD) and tetrahydrocannabinol (THC). Extraction is a used to isolate and concentrate the desired compounds from the cannabis plant. Interest in cannabis extraction and, by extension, in cannabis extraction equipment was rising from earlier as countries legalized its medical and recreational variants.
The Extraction Advantage
Cannabidiol (CBD) is the cannabinoid (compound in cannabis) of most interest due to its healing and non-psychoactive properties. This naturally raises interest in CBD extraction technologies such as cryogenic ethanol extraction and CO2 Extraction. However, full spectrum cannabis extracts that also contain other cannabinoids and non-cannabinoids deliver best results due to synergic impact called “entourage effect”.
Requirements in Extraction
- Lower adulteration in extraction process.
- The extracted solvent should have higher bioactive and lower residues.
- The output should be chemical free.
- Multiple recipe selection.
- Clean, safe and Green Technology.
- Robust process and monitor controlling.
- Operational safety.
- Minimal human intervention.
System Features
Accurate Pressure
Control
Consistent Flow
Control
Superior Sealing
Technology
Unique Extractor
Closure Design
Special Separator
Design
Proprietary Changeover
Valves
Bringing the Future of Extraction to the World
Our team starts by blending principles with practicalities and continue by connecting proven automation process blocks into a holistic solution.
-
Integration:
Combining scientific and engineering principles with a rich and
diversified practical experience to provide innovative solutions
to challenges.
-
Modularity:
Automation based on proven process blocks.
-
Connectivity:
Linking equipment and control systems via PCs and PLCs for
seamless operation.
System Specifications
| Parameters | Level 1 | Level 2 | Level 3 |
|---|---|---|---|
| Single Extractor Volume (Litre) | 5 | 25 | 100 / 200 / 300 |
| No. of Extractors | 2 or 3 | 2 or 3 | 2 or 3 |
| Extractors Usage | Single | Single or Series | Single or Series |
| Pressure Bar (PSI) |
350 - 650 (5000 - 9500) |
350 - 650 (5000 - 9500) |
350 - 650 (5000 - 9500) |
| Temperature — °C (°F) |
70 - 110 (158 - 230 |
70 - 110 (158 - 230 |
70 - 110 (158 - 230 |
| CO2 Recirculation | Yes | Yes | Yes |
| Extractor Changeover Valves | Automatic | Automatic | Automatic |
| CO2 Pump Flowrate (LPH) | 40-80 | 150 - 350 | 600 - 3000 |
| Co-Solvent Pump | Yes | Yes | Yes |
| CO2 Feeding & Recovery System | Included | Included | Included |
| Available Certifications |
CE / U / U2 cGMP / ASME BPE / UL / SIL-3 |
CE / U / U2 cGMP / ASME BPE / UL / SIL-3 |
CE / U / U2 cGMP / ASME BPE / UL / SIL-3 |
| Area Required* (m/ft) |
4.88 x 1.37 x 2.44 / 16 x 4.5 x 8 |
8 x 2.8 x 5.6 / 26 x 27 x 18.5 |
8 x 2.8 x 5.6 / 26 x 27 x 18.5 |
| * All systems can be customized based on the factory layout | |||
Recent Projects
Pilot Scale Extraction System
- Research for Herbal products Extraction
- Capacity: 20L
- Pressure Rating: 650 bar
- Industry: Herbal Pharma Products
- Location: India
Production Scale Extraction System
- Essential Oil Extraction Plant
- Capacity: 300L
- Pressure Rating: 350 bar
- Industry: Essential Oil
- Location: Indonesia
Process flow
Supercritical Fluid Extraction System
Supercritical CO2 utilizes tunable pressure/temperature/batch time to selectively extract cannabinoids and terpenes from cannabis. This method produces clean, solvent-free extracts. Its precise control allows for customizable extract compositions, making it ideal for various product formulations. It's a preferred choice for creating high-quality vape oils and precise pharmaceutical-grade extracts, but there is a need for post-processing for cannabis as shown below.
Cryogenic Ethanol Extraction
Cannabis biomass is soaked in ultra-chilled ethanol, minimizing the extraction of undesirable chlorophyll and waxes. This highly efficient process yields a crude oil rich in cannabinoids, suitable for high-volume production. It's a highly scalable and cost-effective method for producing a cannabinoid-rich base oil, ready for subsequent purification steps as shown below.
Nordex 100
This solventless method uses ice water and gentle agitation to mechanically separate valuable trichomes from cannabis flower. The trichomes are then filtered through a series of micron screens, producing various grades of "bubble hash." This process yields high-quality, pure concentrates, often dried to create a premium, meltable product. It is sometimes further pressed into Rosin as well.
Process flow
Supercritical Fluid Extraction System
Supercritical CO2 utilizes tunable pressure/temperature/batch time to selectively extract cannabinoids and terpenes from cannabis. This method produces clean, solvent-free extracts. Its precise control allows for customizable extract compositions, making it ideal for various product formulations. It's a preferred choice for creating high-quality vape oils and precise pharmaceutical-grade extracts, but there is a need for post-processing for cannabis as shown below.
Cryogenic Ethanol Extraction
Cannabis biomass is soaked in ultra-chilled ethanol, minimizing the extraction of undesirable chlorophyll and waxes. This highly efficient process yields a crude oil rich in cannabinoids, suitable for high-volume production. It's a highly scalable and cost-effective method for producing a cannabinoid-rich base oil, ready for subsequent purification steps as shown below.
Nordex 100
This solventless method uses ice water and gentle agitation to mechanically separate valuable trichomes from cannabis flower. The trichomes are then filtered through a series of micron screens, producing various grades of "bubble hash." This process yields high-quality, pure concentrates, often dried to create a premium, meltable product. It is sometimes further pressed into Rosin as well.
